MNS-100BAS Voice Evacuation Panel

The MNS-100BAS is a state-of-the-art, 100W emergency communications system designed for a variety of voice evacuation applications. It is ideally suited for multi-purpose fire alarm applications as well as weather emergencies and other threats.

The MNS-100BAS accommodates virtually any host alarm system, integrating as quickly and easily as a single primary connection to an NAC output from the FACP.

The MNS-100BAS meets the stringent requirements of NFPA 72, UL864 9th edition, and UFC 4-021-01, making it a fully compliant solution for the most demanding life safety installations.

At its core, the MNS-100BAS features a 100W highly efficient Class D digital audio amplifier driving four selectable speaker circuits configurable for Class A or Class B wiring. A supervised dry contact closure primary activation input connects directly to any FACP NAC output, eliminating complex integration requirements.

The on-board Digital Message Recorder (DMR) includes 2 standard factory-recorded messages — fire and weather — with the option to add up to 8 custom messages. Eight prioritized contact closure activation inputs allow independent message triggering for multi-threat scenarios, while a remote microphone input and auxiliary audio inputs support live paging, background music, and remote system control.

Optional accessories include a remote microphone, common alarm and trouble relays, a 70 Vrms transformer, and an audio power booster function, providing a fully scalable solution for facilities of any size.
